Abendrot Colt DAC
The COLT is a stand-alone D/A converter to be released in celebration of the 10th anniversary of Abendrot high-precision technology. Born from a technologically marvelous True Audio Master Clock and optimal proprietary D/A conversion technology, the COLT was developed with the goal of developing analog audio-like sound while maintaining the inherent resonance and performance characteristics hidden within a digitized music catalog.
The COLT elevates your digital audio to a new dimension; taking you on an unprecedented musical ride that lets you experience euphoric and immersive “depth” and detail”.
MSRP: $53,000
Digital Input
Input 1 AES/EBU XLR 110Ω x1
Input 2 SPDIF Coaxial RCA 75Ω x1
Sampling Rate 16-24bit 44.1kHz-192kHz
Analog Output
Converter Type : Complete Balanced Dual Mono Wide Dynamic Range Topology
Output : XLR Balanced L/R
Output Amplifier : High Voltage Buffered Wide Range DC Amp
Output Impedance : 100Ω (ATT 0dB)
Output Signal Level : 20dBu（7.746Vrms Hi-Z weighted ATT 0dB / 14dBu（3.882Vrms Hi-Z weighted ATT -6dB）
Output Attenuator : 0dB/-6dB Hi-Z weighted
SN Ratio : better than 115dB TYPE
Clock Synchronized Circuit
Input : 10MHz 1V RMS 50Ω/5V P-P Hi-Z
BNC : x1 (Auto Synchronize Connection)
Electrical
Input Voltage : 115V / 230V, 50-60Hz
Wattage 30W(typical)
Environmental
Operating Temperature Range 5℃～ 35℃
Relative humidity : 35～85％RH(non-condensing)
Miscellaneous
Size: 15-3/4" x 16.5" x 4" Overall (W x D x H), Weight: 26 lbs
